Motors for BF40
Standard motors for BF40 conveyors
BF40MOK
This is a selection of BF40MOK standard conveyor sizes. Given speeds are based on using an MS63B-4 with the appropriate SB030 gear.
Recommended max. load 75 kg. The recommended max load is evenly spread over the entire conveyor and is in relation to a nominal width and length.
Dimensions in mm.
For other dimensions please contact Rollco.
Read more
Recommended max. load 75 kg. The recommended max load is evenly spread over the entire conveyor and is in relation to a nominal width and length.
Dimensions in mm.
For other dimensions please contact Rollco.
Product Information
Length (mm): Up to 4000
Gear ratio (I): 5 / 7.5 / 10 / 15 / 20 / 25 / 30 / 40 / 50
Speed (m/min): 37 (37.3) / 25 (24.9) / 19 (18.7) / 12 (12.4) / 9 (9.4) / 8 (7.5) / 6 (6.2) / 5 (4.7) / 4 (3.7)
Drive side: Right/left
Motor Position: Horizontal/vertical — 1-4
Download PDF (all data)
code.product.loadingpdf
+
Add to PDF catalogue
| Designation | Select all | CAD | Compare | Get quote | Lead Time * | Width (mm) |
|---|---|---|---|---|---|---|
|
|
2 | 40 | ||||
|
|
2 | 80 | ||||
|
|
2 | 120 | ||||
|
|
2 | 160 | ||||
|
|
2 | 200 | ||||
|
|
2 | 250 | ||||
|
|
2 | 300 | ||||
|
|
2 | 350 | ||||
|
|
2 | 400 |
*Green: Normally in stock, contact us for current status. Blue: Contact us for delivery time.
-
-
